Southern Pacific Freight Car Specification Sheet 20

Containers - 1965


Page 1


Page 2

Container Series
Numbers

S.P. & P.F.E.
No. of
Containers
Capacity Inside Dimensions Outside Dimensions Door Opening Insulated
Cubic
Feet
Average
Light
Weight
Load
Limit
Length Width Height Length Width Height Width Height
PMTZ 900001
to 900020
20 2,374 7,560 42,000 39' 4" 7' 8" 7' 10½" 40' 0" 8' 0" 8' 6" 7' 6" 7' 6¾" NO
PMTZ 910001
to 910060
60 1,162 4,900 40,000 19' 3" 7' 8" 7' 10½" 19' 10" 8' 0" 8' 6" 7' 6" 7' 6¾" NO
PFC 101
to 112
12 1,329 5,000 40,000 23' 4" 7' 7" 7' 5" 24' 0" 8' 0" 8' 6" 7' 6" 7' 6" YES
